Technical Specifications: arm-free portable CMM HandyPROBE

Stylus

Weight 450 g (1 lb)
Dimensions 204 x 159 x 97 mm (8 x 6.26 x 3.8 in)
Measurement speed 30 points/s
Operating temperature range 15-40 °C (59-104 °F)
Operating humidity range (non-condensing) 10-90%
Certification EN 301 489-1, EN 301 489-3, EN 300 220-1

C-Track

  C-Track 380 C-Track 780 C-Track 1480
ACCURACY (1) Up to 0.022 mm (0.0009 in.) Up to 0.025 mm (0.0010 in.) Up to 0.030 mm (0.0012 in.)
SINGLE POINT
REPEATABILITY (3)
3.80 m3 (135 ft3) 0.045 mm (2) (0.0018 in.) 0.050 mm (5)(0.0020 in.) 0.055 mm (5) (0.0022 in.)
7.80 m3 (275 ft3) n/a 0.055 mm (2) (0.0022 in.) 0.065 mm (5) (0.0026 in.)
14.8 m3 (525 ft3) n/a n/a 0.095 mm (2)(0.0037 in.)
VOLUMETRIC
ACCURACY (4)
3.80 m3 (135 ft3) 0.075 mm (2) (0.0029 in.) 0.080 mm (5) (0.0031 in.) 0.090 mm (5) (0.0035 in.)
7.80 m3 (275 ft3) n/a 0.085 mm (2) (0.0033 in.) 0.095 mm (5) (0.0038 in.)
14.8 m3 (525 ft3) n/a n/a 0.170 mm (2) (0.0067 in.)
VOLUMETRIC ACCURACY
(with MaxSHOT 3D or C-Link)(4)
0.075 mm if L ≤ 1.2 m 0.085 mm if L ≤ 1.2 m 0.170 mm if L ≤ 3.0 m
0.045 mm + 0.025 mm/m
if L >1.2 m
0.055 mm + 0.025 mm/m
if L >1.2 m
0.095 mm + 0.025 mm/m
if L >3.0 m
MEASUREMENT SPEED 30 Hz
WEIGHT 5,5 kg (12 lbs.)
DIMENSIONS 1035 x 169 x 140 mm (40.8 x 6.6 x 5.5 in.)
OPERATING TEMPERATURE RANGE 15–40 oC (59-104 oF)
OPERATING HUMIDITY RANGE
(NON CONDENSING)
10–90 %
CERTIFICATIONS EN 301 489-1, EN 301 489-3, EN 300 220-1

(1) Volumetric accuracy using dynamic referencing mode and a 500 mm artefact.
(2) Each system tested according test methods given in the ASME B89.4.22 standard.
(3)Single point repeatability: The probe of the HandyPROBE is located within a conical socket. Individual points are measured from multiple approach directions. Each individual point measurement is analyzed as a range of deviations in X, Y, Z (distance/2 method).
(4) Volumetric accuracy: Performance is assessed by measuring traceable length artifacts in different locations and with different orientations within the working volume of the HandyPROBE (distance/2 method).
(5) Typical value.
