Technical Specifications
Peel 3 is an easy and intuitive technology that will bring portability, versatility, and ease of use to your educational 3D scanning projects.
Software
Peel.OS, Peel.CAD(1), Peel.CAD Pro(2)
Recommended object size
0.1 - 3.0 m (0.3–10 ft)
Accuracy
up to 0.050 mm (0.0020 in)
Volumetric accuracy
0.050 mm + 0.100 mm/m (0.0020 in + 0.0012 in/ft)
Measurement capabilities
Pin1.5 mm (0.059 in)
Hole3.0 mm (0.118 in)
Step0.1 mm (0.0039 in)
Wall1.0 mm (0.039 in)
Mesh resolution
0.250 mm (0.01 in)
Scanning area
340 x 475 mm (13.39 x 18.7 in)
Scan speed
80 sec/m2 (7.4 sec/ft2)
Usage distance (from objects)
USB 3.0250 to 550 mm (9.8 to 21.7 in)
Depth of field
300 mm (11.8 in)
Projector light source
IR VCSEL
Scanner controls
Touchscreen
Color resolution (on objects)
50 to 200 DPI
Positioning methods
Geometry and/or targets and/or texture
Mesh resolution
1,250,000 measurements/s
Dimensions
304 x 150 x 79 mm (12 x 5.9 x 3.2 in)
Weight
950 g (2.1 lb)
Connectivity
USB 3.0
Output formats (Peel 3)
.dae, .fbx, .ma, .obj, .ply, .stl, .txt, .wrl, .x3d, .x3dz, .zpr, .dxf, .3mf, .iges(1)(2), .step(1)(2)
