RECOMMENDED SYSTEM REQUIREMENTS



MINIMUM REQUIREMENTS

RECOMMENDED SPECIFICATIONS

Processor(1)

Intel Core i7 (6+ cores) – 2.3 GHz or more

Intel Core i7 (8 cores) – 2.5 GHz or more

Operating System(2)

Windows 10 (64 bits)(3)(4)

Graphics Card(5)(6)

NVIDIA (6 GB VRAM)

OpenGL 4.5 and higher,
Compute Capability 6.1


NVIDIA Quadro RTX A5000 (16 GB VRAM)

Memory

32 GB

64 GB

Hard Drive

Solid-state drive (SSD)

with at least 200 GB of free space


1 TB SSD

Display

1920 X 1080

Connecting Port

SuperSpeed USB 3.0 Type-A

Microsoft Excel(7)

Excel 2016+

(1) Processor must support AVX2 instructions

(2) 32-bits OS are not supported.

(3) Windows 10 version 1909 or higher.

(4) .NET Microsoft Framework version: 4.7.2

(5) GPU memory requirements are proportional to the amount of data collected in a single-scan session. Scanning large parts with higher resolution may exceed the minimum specs and require merging scans.

(6) Only NVIDIA graphic cards are supported. Recommended NVIDIA driver version: 465+

(7) Microsoft Excel® is required for the following software: Pipecheck™, Pipecheck Analyze, and SmartDENT 3D™. Microsoft Excel® is required to export XLS reports in VXinspect.
